Handheld bug detector and RF transmitter finder. Can detect many RF devices such as GSM, UMTS, 3G, CDMA mobile phones, cordless, bluetooth/wireless etc.
The RIL-RF-DIR digital directional bug detector can be used to detect and locate a wide range of radio transmitters (radio transmitters, GSM bugs, hidden cameras etc.) usually used to make unauthorized access to data and information.
It is a superheterodyne receiver and frequency synthesizer, which provides continuous scanning of the frequencies being in its range and the analysis of the spectrogram peaks. Standard digital signals are identified by their amplitude and frequency modulation characteristics. Scanning and analysis take place cyclically every 1.0-1.5 sec.
The device can control, scan, search and monitor analog and digital signals and it is able also to detect GSM900/1800, UMTS (3G), CDMA 450 (453-458 MHz), UMTS 900 cell phones, cordless, bluetooth and wireless devices as well as many other analog and digital radio equipment.
Selective reception of radio signals.
High speed of scanning and analyzing.
Detection of wideband and digital signals.
Adaptation to the background noise.
Difference search mode.
Signal frequency and level measurement.
Alarm events log.
Soundless alarm indication (vibration mode).
No need for external antenna.
Frequency band: 50-3800МHz
Typical sensitivity: 70mV/m
Dynamic range: 50dB
Period of full scanning cycle: ≤ 1.5s
Running time in Guard mode: 4-12h
Display: OLED 128 x 64
Size: 43 x 77 x 18 mm
Detection of bugs or radio transmission equipment in general, with the possibility of identifying the type of signal beyond the frequency (e.g. UMTS, GSM, CDMA etc.)
For bug sweeping operations carried out by sector specialists as well as for private home made remediation
